F17+

AVer | AverVision F17+ - Flexible Arm Visualizer

1/3.06" CMOS sensor

4K 60fps

23X digital zoom

A3 shooting area

180Â° rotation

AVerVision F17+ is a visualizer for every classroom. Its 13 megapixel camera offers 4K image quality, allowing you to easily present teaching materials with its 23X zoom feature. Helping inspire students' boundless creativity through hybrid interactive learning has never been easier with F17+.

PRODUCT SPECIFICATION

Image Sensor	1/3.06" CMOS color image sensor
Total Pixels	13M
Output Resolution	HDMI: 4K at 60 / 30Hz, Full HD 1080p at 60Hz, HD 720p at 60Hz, VGA: Full HD 1080p at 60Hz, HD 720p at 60Hz
TV lines	1,500 (max.)
Zoom	23X Digital Zoom
Frame Rate	60fps (max.)
Focus	Auto / Manual
Shooting Area	Larger than A3 landscape
Image Rotation	0Â° / 180Â°
Internal Storage	200 Pictures at XGA (1024 x 768)
External Storage	SDHC Card & USB Thumb Drive (Up to FAT32 / 32 GB)
One-touch Recording	Yes
One-touch Capturing	Yes
Image Effects	Color / B&W / Negative
Image Adjustments (White Balance / Exposure)	Auto / Manual
Display Modes	Normal / Motion / High Quality
Capture Modes	Single / Continuous
User Profiles	Yes, up to 3
Timer	Yes
Flicker Filter Control	Yes
ePTZ	Yes
Light Source	Embedded LED lamp
HDMI I/O	1 in; 1 out
VGA I/O	1 in; 1 out
USB 2.0 ports	Type-A x 1 (USB Thumb Drive), Type-C x 1 (PC)
Audio	Line out (3.5 mm), Mic in (3.5 mm), Built-in Mic
Security	Kensington Slot
Dimensions	Operating: 200 x 380 x 525 mm, Folded: 230 x 305 x 73 mm
Net Weight	2.5 kg (5.51 lbs)
Power Source	DC 12V / 2A, AC 100 to 240V, 50 / 60Hz
Power Consumption	10 Watts (Lamp on); 9 Watts (Lamp off)
Warranty	Visualizer: 5 Years; Accessories: 1 Year
Software	AVerTouch, Sphere Lite
WindosÂ®OS	WindowsÂ® 7, 10, 11
MacÂ®OS	macOSÂ® X 10.15, 11, 12
Chromeâ„¢ OS	Chromeâ„¢ OS 88 or later (Available via the Sphere Lite App only)
Optional Accessories	Microscope Adaptor, Anti-Glare Sheet, Carrying Bag
Package Content	AVerVision F17+, USB Type-A to Type-C Cable, VGA Cable, Power Adapter, Remote Control, Quick Start Guide
