LUMENS
LC300S
4 Channel UHD Media Processorwith NDI and 12G-SDI
- 4 HDMI and IP video source
- UHD image
- 12G-SDI HDMI USB IP and NDI connectivity
- USB output for video conferencing
Lumens LC300S is a 4K multi-channel media processor with 12G-SDI, HDMI, USB, IP and NDI connectivity. As a lecture capture system, live event switcher or multi-purpose AV encoder, the LC300S delivers an exceptional user experience. Key features include video mixing, recording, and live streaming.
Specs
Video Input
Number / Signal
HDMI 2.0 x 1
HDMI 1.3 x 3
3G-SDI x 1
12G-SDI x 1
HDMI 1.3 x 3
3G-SDI x 1
12G-SDI x 1
Connection
Female HDMI type-A / 3G-SDI / 12G-SDI
Resolution Range
HDMI Input 1: 720p~2160p 60fps, 1920x1200(RB)
HDMI Input 2~4 and 3G-SDI: 720p~1080p 60fps
12G-SDI: 720p~2160p 60fps
HDMI Input 2~4 and 3G-SDI: 720p~1080p 60fps
12G-SDI: 720p~2160p 60fps
IP Source / USB Camera
Lumens IP PTZ / Box Camera
NDI High Bandwidth, NDI HX2 and NDI HX3 Source
RTSP Source (HEVC(H.265), H.264), SRT
USB Camera (MJPEG 1080p 30fps)
NDI High Bandwidth, NDI HX2 and NDI HX3 Source
RTSP Source (HEVC(H.265), H.264), SRT
USB Camera (MJPEG 1080p 30fps)
Video Processing
Video Compression
HEVC (H.265) / H.264 / AVC 4:2:0 8bit color
Encoding Profile: High, Main, Baseline
Encoding Profile: High, Main, Baseline
Video Output
Number / Signal
HDMI x 2
HDMI Loop-through x 1
12G-SDI Loop-through x 1
UVC(up to 1080p) x 1
HDMI Loop-through x 1
12G-SDI Loop-through x 1
UVC(up to 1080p) x 1
Scaled Resolution
2160p / 1080p
Frame Rate
60 / 50 / 30 / 25 fps
Monitor
2 inch color LCD screen
Recording and Storage
Internal Storage
4TB HDD
External Storage
USB Storage
File Type
H.264 / HEVC(H.265) and AAC in an MP4 container, JPEG
Resolution
2160p / 1080p / 720p / 480p / 360p
Frame Rate
Max. 60 fps
Audio Input
Number / Signal
Line In (Stereo Unbalanced Audio, 3.5mm Phone Jack) x 2
Combo (XLR/TRS, Balanced Audio, Line in/ Mic in, Support +48V Phantom Power) x 2
IP Audio Source (RTSP(AAC-RAW), NDI, 16K/44.1K/48K)
Support UAC
Combo (XLR/TRS, Balanced Audio, Line in/ Mic in, Support +48V Phantom Power) x 2
IP Audio Source (RTSP(AAC-RAW), NDI, 16K/44.1K/48K)
Support UAC
Audio Processing
Compression
AAC-LC
Audio Output
Number / Signal
XLR, Balanced Audio, Line Out x 2
Stereo, Unbalanced 3.5mm Phone Jack x 2
Stereo, Digital De-embedded Audio from HDMI x 2
USB (UAC) x 1
Stereo, Unbalanced 3.5mm Phone Jack x 2
Stereo, Digital De-embedded Audio from HDMI x 2
USB (UAC) x 1
Communication
USB
USB 2.0 Type A x 2
USB 3.0 Type A x 2
Support USB Storage, USB Camera, USB Mic
USB Mouse, Keyboard, HID Touch Display
USB 3.0 Type-B (UVC / UAC) x 1
USB 3.0 Type A x 2
Support USB Storage, USB Camera, USB Mic
USB Mouse, Keyboard, HID Touch Display
USB 3.0 Type-B (UVC / UAC) x 1
Serial Control
RS-232 In /RS-232 out
Ethernet
Ethernet host port
Female RJ-45 x 2
10 / 100 / 1000 Base-T High / Full Duplex
10 / 100 / 1000 Base-T High / Full Duplex
Streaming Protocol
Pull: RTSP / NDI High Bandwidth / NDI HX
Push: RTMP / RTMPS / MPEG-TS / SRT / TCP, UDP, HTTP
DHCP Client
Push: RTMP / RTMPS / MPEG-TS / SRT / TCP, UDP, HTTP
DHCP Client
Functions
Support IP Sources
Lumens IP Camera, RTSP, NDI
Scenes switch
Yes (Preset for Layout, Background, and Overlay)
Layout switch
Yes (Single, PIP, PBP, 3 and 4 windows layouts)
Background switch
Yes
Overlay
Yes (PNG Overlay)
File backup
FTP / SFTP / NAS (CIFS / SMB, NFS) / WebDAV / USB Storage
Content Management Systems
Panopto / OpenCast / Kaltura
General
Power supply
DC In , 19V / 6.8A
Power consumption
130W
Dimensions: (WxHxD)
Standard 1.5U rack
16.6" x 8.48" x 2.58" ( 422 x 215.5 x 65.5 mm )
16.6" x 8.48" x 2.58" ( 422 x 215.5 x 65.5 mm )
Weight
7.72 lbs (3.5 Kg)
