NUREVA
HDL410
Meeting Room Audio Device
- Microphone Mist technology
- Built-in sound masking
- 4 x 20W speaker
- Connect module
The HDL410 system delivers pro AV performance without the cost and complexity of a custom pro AV system. It combines a powerful connect module with two integrated microphone and speaker bars to offer advanced processing and premium features for extra-large spaces up to 10.7 x 16.8m. Equipped with Microphone Mist™ technology, these devices offer a high-level sound experience.
Specs
Technology features
Advanced Microphone Mist technology processing platform
Unified coverage map
Continuous autocalibration
Position-based gain control
Acoustic echo cancellation
Built-in sound masking
Plug and play — no software or drivers required
Ethernet cables - each microphone and speaker bar
Primary audio source for video playback
Integrated, multicolor status LED
Unified coverage map
Continuous autocalibration
Position-based gain control
Acoustic echo cancellation
Built-in sound masking
Plug and play — no software or drivers required
Ethernet cables - each microphone and speaker bar
Primary audio source for video playback
Integrated, multicolor status LED
Microphones
24 low-noise omnidirectional MEMS (12 in each microphone and speaker bar)
Frequency response at 94 dB SPL 100 Hz to 7 kHz
Total harmonic distortion (THD)
0.25% (typical)
Frequency response at 94 dB SPL 100 Hz to 7 kHz
Total harmonic distortion (THD)
0.25% (typical)
Speakers
4 x 20 W 4" aluminum cone (2 in each microphone and speaker bar)
Acoustic output (hardware capable): 91 dB SPL @ 1 m
Total harmonic distortion (THD): 0.25% (typical)
Acoustic output (hardware capable): 91 dB SPL @ 1 m
Total harmonic distortion (THD): 0.25% (typical)
Connect module
USB 2.0 interface to computer or collaboration hub, type B
Auxiliary out — 3.5 mm single-ended stereo jack
Auxiliary in — 3.5 mm single-ended stereo jack
2 connections to microphone and speaker bars RJ45
Console Direct RJ45 for connecting to network
Input jack for power supply
Auxiliary out — 3.5 mm single-ended stereo jack
Auxiliary in — 3.5 mm single-ended stereo jack
2 connections to microphone and speaker bars RJ45
Console Direct RJ45 for connecting to network
Input jack for power supply
Interoperability
Plug and play compatibility with UC&C platforms including Microsoft® Teams, Zoom, Google Meet™, GoTo Meeting, Cisco Webex®, BlueJeans, Lifesize®, RingCentral Meetings™ and more
Easy integration with third-party solutions such as Barco ClickShare, lecture capture systems and headset microphones (for Voice Amplification Mode)
Easy integration with third-party solutions such as Barco ClickShare, lecture capture systems and headset microphones (for Voice Amplification Mode)
System Requirements
Windows® 10 and 11, macOS® 10 and 11 (Big Sur and Catalina)
Power
Power rating: universal switching 100–240 V AC, 50–60 Hz
Power consumption: <30 W
Power consumption: <30 W
Operating Temperature
0° C to 40° C (32° F to 104° F)
Storage Temperature
-20° C to 70° C (-4° F to 158° F),
Humidity
5–90% (noncondensing)
Manageability
Includes Console Direct, which provides a continuous and secure connection to Nureva Console, our cloud-based device management platform
Console Direct Security Features
Secure IoT OS and system software with device-specific X.509 certificates and external services encrypted using 256-bit Transport Layer Security (TLS)
Information security management system (ISMS) that is ISO/IEC 27001:2013 certified
Built with Microsoft Azure, all data at rest is encrypted using 256-bit AES encryption, and data in transit uses TLS 1.2
Okta Identity Cloud for all identity and access management (IAM) services with OAuth 2.0 protocols to identify and authorize users
Information security management system (ISMS) that is ISO/IEC 27001:2013 certified
Built with Microsoft Azure, all data at rest is encrypted using 256-bit AES encryption, and data in transit uses TLS 1.2
Okta Identity Cloud for all identity and access management (IAM) services with OAuth 2.0 protocols to identify and authorize users
Certifications and Compatibility
Electromagnetic: FCC Part 15, Class A; ICES-003, Class A; CISPR 32 (EN 55032), Class A; CISPR 35, (EN 55035); CISPR 24 (EN 55024)
Safety: UL 62368; CAN/CSA-C22.2 NO.62368; IEC/EN 62368; AS/NZS 62368; UL 60950; CAN/CSA-C22.2 NO.60950; IEC/EN 60950; AS/NZS 60950
Compliance: RoHS, REACH, POPs (Persistent Organic Pollutants), WEEE, California Proposition 65, EPA (TSCA — Toxic Substances Control Act) Restrictions
Safety: UL 62368; CAN/CSA-C22.2 NO.62368; IEC/EN 62368; AS/NZS 62368; UL 60950; CAN/CSA-C22.2 NO.60950; IEC/EN 60950; AS/NZS 60950
Compliance: RoHS, REACH, POPs (Persistent Organic Pollutants), WEEE, California Proposition 65, EPA (TSCA — Toxic Substances Control Act) Restrictions
