VIVITEK

DU9057Z

Vivitek 27000 Lumen Lazer Projector

  • 27000 ANSI Lumen
  • WUXGA (1920 x 1200)
  • 3 000 000:1 contrast
  • 40'' - 600'' image

The DU9057Z is designed for ProAV rental, staging and large venue applications. The Single Chip WUXGA laser projector offers a constant light output of 27,000 lumens and a 3,000,000:1 dynamic contrast ratio. The Constant Brightness feature helps reduce blending maintenance with a smart sensor continuously measuring and adjusting the illumination output. The projector can run continuously for 30,000 hours in Eco Mode, guaranteeing 24/7 operation with low user intervention.

Vivitek DU9057Z

Specs

Projector
Native Resolution
WUXGA (1920 x 1200)
Brightness
27000 ANSI Lumens
Contrast Ratio
3 000 000:1 (Dynamic)
Max. Supported Resolution
4K UHD (3840x2160) @60Hz
Native Aspect Ratio
16:10
Display Type
DLP Technology by TI
Chip Size
Single Chip 0.96`` DMD
Throw Ratio
7 optional lenses from 0.38:1 to 10.3:1 throw ratio range
Image Size (Diagonal)
Depending on lens selection
Projection Distance
Depending on lens selection
Zoom Ratio
Motorized Zoom & Focus
Lens Shift Range
Vertical: +/-50%; Horizontal: +/-15%
Keystone Correction
Vertical: +/-40 Steps; Horizontal: +/-45 Steps
Vertical Scan Rate
24~30Hz ;47~120Hz
Horizontal Scan Rate
15.31 ~ 135 kHz
Video Compatibility
SDTV (480i, 576i), EDTV (480p, 576p), HDTV (720p, 1080i/p, 4K-UHD)
I/O Connection Ports
HDMI (2x), Display Port, DVI-D, Component (5 BNC) (RGBHV) , RJ45 (1x: HDBaseT/LAN), 12v Trigger (x1), RS-232, 3G-SDI (2x: In and Out), USB A (x1 with Power), Remote Jack(wire remote)
Dimensions (W x D x H)
676.6 x 598.8 x 270mm
Weight
45.4 kg
Noise Level
43dB / 40dB (Normal / Eco)
AC 100-240V, 50/60Hz Consumption: 1500W (Normal Mode) <0.5W (Standby)
Supply:
Control Software
PJ - Control +V3.0.0.4
Optional Accessories
Remote Control P/N: 5042221900
Warranty
Large Venue Laser Phosphor Warranty: 5 Year projector / 5 years or 20.000h on the Laser Phosphor illumination source.(Whichever comes first)
UPC Code
DU9057Z-BK: 813097025814
Lens 1: Ultra Short Throw
Aspect Ratio
16:10
Throw Ratio
0,38
Projection Distance
1,6 - 5
Image Size
200 - 600
Zoom
Fixed zoom
F Number
2,4
Focal Length
8.20mm
Part Number
SS-3796100268-VV(D98-UST01)
Lens 2: Normal Throw
Aspect Ratio
16:10
Throw Ratio
1.25 - 1.56:1
Projection Distance
0.95 - 17.47
Image Size
40 - 500
Zoom
1.3X
F Number
2.18 ~ 2.66
Focal Length
25.69 ~ 33.22
Part Number
SS-3796100205 - VV(D99-1215)
Lens 3: Standard Lens
Aspect Ratio
16:10
Throw Ratio
1.50 - 2.00:1
Projection Distance
1.24 - 21.84
Image Size
40 - 500
Zoom
1.33X
F Number
2.17 - 2.65
Focal Length
31.9 - 42.2 mm
Part Number
SS-3796100203-VV(D99-1520)
Lens 4: Long Throw 1
Aspect Ratio
16:10
Throw Ratio
2.00 - 4.00:1
Projection Distance
2.65 - 41.77
Image Size
40 - 500
Zoom
2.0X
F Number
2.17 ~ 2.64
Focal Length
42.6 ~ 84.8 mm
Part Number
SS-3796100204-VV(D99-2040)
Lens 5: Long Throw 2
Aspect Ratio
16:10
Throw Ratio
4.00 ~ 7.00: 1
Projection Distance
4.38 - 74.51
Image Size
50 - 500
Zoom
1.7X
F Number
2.20 - 2.57
Focal Length
83.93 - 146.85 mm
Part Number
SS-3796100206-VV(D99-4070)
Lens 6: Long Throw 3
Aspect Ratio
16:10
Throw Ratio
6.90 ~ 10.30:1
Projection Distance
12 - 80
Image Size
50 - 500
Zoom
1.49X
F Number
2.5
Focal Length
140.1 ~ 209.6 mm
Part Number
SS-3796100269-VV(D98-69103)

Documents

Datasheet (EN) PDF

Accessories

5042221900

5042221900

Lenses

D98-UST01

D98-UST01

Ultra Short Throw
Ayım Oranı: 0.38
Parça No: SS-3796100268-VV

D99-0912

D99-0912

Short Throw (F)
Throw Ratio: 0.9~1.2 : 1
Part Number: SS-3796100207-VV

D99-1215

D99-1215

Normal Throw 1
Atım Oranı: 1.25 – 1.56:1
Parça No: SS-3796100205-VV

D99-1520

D99-1520

Standard Lens
Atım Oranı: 1.50-2.00:1
Parça No: SS-3796100203-VV

D99-2040

D99-2040

Long Throw 1
Atım Oranı: 2.00-4.00:1
Parça No: SS-3796100204-VV

D99-4070

D99-4070

Long Throw 2
Atım Oranı: 4.00~7.00: 1
Parça No: SS-3796100206-VV

D98-69103

D98-69103

Long Throw 3
Atım Oranı: 6.90~ 10.30:1
Parça No: SS-3796100269-VV
